CHAPTER SEVENTEEN:
INTERRUPTS TRAPS AND EXEPTIONS (Part 2)
17.3 - Exceptions
17.3.1 - Divide Error Exception (INT 0)
17.3.2 - Single Step (Trace) Exception (INT 1)
17.3.3 - Breakpoint Exception (INT 3)
17.3.4 - Overflow Exception (INT 4/INTO)
17.3.5 - Bounds Exception (INT 5/BOUND)
17.3.6 - Invalid Opcode Exception (INT 6)
17.3.7 - Coprocessor Not Available (INT 7)
17.3 Exceptions

Exceptions occur (are raised) when an abnormal condition occurs during execution. There are fewer than eight possible exceptions on machines running in real mode. Protected mode execution provides many others but we will not consider those here we will only consider those exceptions interesting to those working in real mode[4].

Although exception handlers are user defined the 80x86 hardware defines the exceptions that can occur. The 80x86 also assigns a fixed interrupt number to each of the exceptions. The following sections describe each of these exceptions in detail.

In general an exception handler should preserve all registers. However there are several special cases where you may want to tweak a register value before returning. For example if you get a bounds violation you may want to modify the value in the register specified by the bound instruction before returning. Nevertheless you should not arbitrarily modify registers in an exception handling routine unless you intend to immediately abort the execution of your program.

17.3.1 Divide Error Exception (INT 0)

This exception occurs whenever you attempt to divide a value by zero or the quotient does not fit in the destination register when using the div or idiv instructions. Note that the FPU's fdiv and fdivr instructions do not raise this exception.

MS-DOS provides a generic divide exception handler that prints a message like "divide error" and returns control to MS-DOS. If you want to handle division errors yourself you must write your own exception handler and patch the address of this routine into location 0:0.

On 8086 8088 80186 and 80188 processors the return address on the stack points at the next instruction after the divide instruction. On the 80286 and later processors the return address points at the beginning of the divide instruction (include any prefix bytes that appear). When a divide exception occurs the 80x86 registers are unmodified; that is they contain the values they held when the 80x86 first executed the div or idiv instruction.

When a divide exception occurs there are three reasonable things you can attempt: abort the program (the easy way out) jump to a section of code that attempts to continue program execution in view of the error (e.g. as the user to reenter a value) or attempt to figure out why the error occurred correct it and reexecute the division instruction. Few people choose this last alternative because it is so difficult.

17.3.2 Single Step (Trace) Exception (INT 1)

The single step exception occurs after every instruction if the trace bit in the flags register is equal to one. Debuggers and other programs will often set this flag so they can trace the execution of a program.

When this exception occurs the return address on the stack is the address of the next instruction to execute. The trap handler can decode this opcode and decide how to proceed. Most debuggers use the trace exception to check for watchpoints and other events that change dynamically during program execution. Debuggers that use the trace exception for single stepping often disassemble the next instruction using the return address on the stack as a pointer to that instruction's opcode bytes.

Generally a single step exception handler should preserve all 80x86 registers and other state information. However you will see an interesting use of the trace exception later in this text where we will purposely modify register values to make one instruction behave like another.

Interrupt one is also shared by the debugging exceptions capabilities of 80386 and later processors. These processors provide on-chip support via debugging registers. If some condition occurs that matches a value in one of the debugging registers the 80386 and later CPUs will generate a debugging exception that uses interrupt vector one.

17.3.3 Breakpoint Exception (INT 3)

The breakpoint exception is actually a trap not an exception. It occurs when the CPU executes an int 3 instruction. However we will consider it an exception since programmers rarely put int 3 instructions directly into their programs. Instead a debugger like Codeview often manages the placement and removal of int 3 instructions.

When the 80x86 calls a breakpoint exception handling routine the return address on the stack is the address of the next instruction after the breakpoint opcode. Note however that there are actually two int instructions that transfer control through this vector. Generally though it is the one-byte int 3 instruction whose opcode is 0cch; otherwise it is the two byte equivalent: 0cdh 03h.

17.3.4 Overflow Exception (INT 4/INTO)

The overflow exception like int 3 is technically a trap. The CPU only raises this exception when you execute an into instruction and the overflow flag is set. If the overflow flag is clear the into instruction is effectively a nop if the overflow flag is set into behaves like an int 4 instruction. Programmers can insert an into instruction after an integer computation to check for an arithmetic overflow. Using into is equivalent to the following code sequence:

         << Some integer arithmetic code
                jno      GoodCode
                int      4
GoodCode:

One big advantage to the into instruction is that it does not flush the pipeline or prefetch queue if the overflow flag is not set. Therefore using the into instruction is a good technique if you provide a single overflow handler (that is you don't have some special code for each sequence where an overflow could occur).

The return address on the stack is the address of the next instruction after into. Generally an overflow handler does not return to that address. Instead it will usually abort the program or pop the return address and flags off the stack and attempt the computation in a different way.

17.3.5 Bounds Exception (INT 5/BOUND)

Like into the bound instruction will cause a conditional exception. If the specified register is outside the specified bounds the bound instruction is equivalent to an int 5 instruction; if the register is within the specified bounds the bound instruction is effectively a nop.

The return address that bound pushes is the address of the bound instruction itself not the instruction following bound. If you return from the exception without modifying the value in the register (or adjusting the bounds) you will generate an infinite loop because the code will reexecute the bound instruction and repeat this process over and over again.

One sneaky trick with the bound instruction is to generate a global minimum and maximum for an array of signed integers. The following code demonstrates how you can do this:

; This program demonstrates how to compute the minimum and maximum values
; for an array of signed integers using the bound instruction

.xlist
.286
include         stdlib.a
includelib      stdlib.lib
.list

dseg            segment para public 'data'

; The following two values contain the bounds for the BOUND instruction.

LowerBound      word    ?
UpperBound      word    ?

; Save the INT 5 address here:

OldInt5         dword   ?

; Here is the array we want to compute the minimum and maximum for:

Array           word    1
2
-5
345
-26
23
200
35
-100
20
45
word    62
-30
-1
21
85
400
-265
3
74
24
-2
word    1024
-7
1000
100
-1000
29
78
-87
60
ArraySize       =       ($-Array)/2

dseg            ends


cseg            segment para public 'code'
assume  cs:cseg
ds:dseg


; Our interrupt 5 ISR. It compares the value in AX with the upper and
; lower bounds and stores AX in one of them (we know AX is out of range
; by virtue of the fact that we are in this ISR).
;
; Note: in this particular case
we know that DS points at dseg
so this
; ISR will get cheap and not bother reloading it.
;
; Warning: This code does not handle the conflict between bound/int5 and
; the print screen key. Pressing prtsc while executing this code may
; produce incorrect results (see the text).

BoundISR        proc    near
cmp     ax
LowerBound
jl      NewLower

; Must be an upper bound violation.

mov     UpperBound
ax
iret

NewLower:       mov     LowerBound
ax
iret
BoundISR        endp

Main            proc
mov     ax
dseg
mov     ds
ax
meminit

; Begin by patching in the address of our ISR into int 5's vector.

mov     ax
0
mov     es
ax
mov     ax
es:[5*4]
mov     word ptr OldInt5
ax
mov     ax
es:[5*4 + 2]
mov     word ptr OldInt5+2
ax

mov     word ptr es:[5*4]
offset BoundISR
mov     es:[5*4 + 2]
cs


; Okay
process the array elements. Begin by initializing the upper
; and lower bounds values with the first element of the array.

mov     ax
Array
mov     LowerBound
ax
mov     UpperBound
ax

; Now process each element of the array:

mov     bx
2                   ;Start with second element.
mov     cx
ArraySize
GetMinMax:      mov     ax
Array[bx]
bound   ax
LowerBound
add     bx
2                   ;Move on to next element.
loop    GetMinMax               ;Repeat for each element.

printf
byte    "The minimum value is %d\n"
byte    "The maximum value is %d\n"
0
dword   LowerBound
UpperBound

; Okay
restore the interrupt vector:

mov     ax
0
mov     es
ax
mov     ax
word ptr OldInt5
mov     es:[5*4]
ax
mov     ax
word ptr OldInt5+2
mov     es:[5*4+2]
ax


Quit:           ExitPgm                 ;DOS macro to quit program.
Main            endp

cseg            ends

sseg            segment para stack 'stack'
stk             db      1024 dup ("stack ")
sseg            ends

zzzzzzseg       segment para public 'zzzzzz'
LastBytes       db      16 dup (?)
zzzzzzseg
ends
end     Main

If the array is large and the values appearing in the array are relatively random this code demonstrates a fast way to determine the minimum and maximum values in the array. The alternative comparing each element against the upper and lower bounds and storing the value if outside the range is generally a slower approach. True if the bound instruction causes a trap this is much slower than the compare and store method. However it a large array with random values the bounds violation will rarely occur. Most of the time the bound instruction will execute in 7-13 clock cycles and it will not flush the pipeline or the prefetch queue[5].

Warning: IBM in their infinite wisdom decided to use int 5 as the print screen operation. The default int 5 handler will dump the current contents of the screen to the printer. This has two implications for those who would like to use the bound instruction in their programs. First if you do not install your own int 5 handler and you execute a bound instruction that generates a bound exception you will cause the machine to print the contents of the screen. Second if you press the PrtSc key with your int 5 handler installed BIOS will invoke your handler. The former case is a programming error but this latter case means you have to make your bounds exception handler a little smarter. It should look at the byte pointed at by the return address. If this is an int 5 instruction opcode (0cdh) then you need to call the original int 5 handler or simply return from interrupt (do you want them pressing the PrtSc key at that point?). If it is not an int 5 opcode then this exception was probably raised by the bound instruction. Note that when executing a bound instruction the return address may not be pointing directly at a bound opcode (0c2h). It may be pointing at a prefix byte to the bound instruction (e.g. segment addressing mode or size override). Therefore it is best to check for the int 5 opcode.

17.3.6 Invalid Opcode Exception (INT 6)

The 80286 and later processors raise this exception if you attempt to execute an opcode that does not correspond to a legal 80x86 instruction. These processors also raise this exception if you attempt to execute a bound lds les lidt or other instruction that requires a memory operand but you specify a register operand in the mod/rm field of the mod/reg/rm byte.

The return address on the stack points at the illegal opcode. By examining this opcode you can extend the instruction set of the 80x86. For example you could run 80486 code on an 80386 processor by providing subroutines that mimic the extra 80486 instructions (like bswap cmpxchg etc.).

17.3.7 Coprocessor Not Available (INT 7)

The 80286 and later processors raise this exception if you attempt to execute an FPU (or other coprocessor) instruction without having the coprocessor installed. You can use this exception to simulate the coprocessor in software.

On entry to the exception handler the return address points at the coprocessor opcode that generated the exception.


[4] For more details on exceptions in protected mode see the bibliography.

[5] Note that on the 80486 and later processors the bound instruction may actually be slower than the corresponding straight line code.
